CNC Router Kompas F3000

Code: F3000
7 700 € 9 240 € incl. VAT
4-8 weeks
Computer
CAD/CAM Software
4th rotary axis
Extraction
Delivery offer
  • Work space: 1250 x 2600 x 250 mm
  • Maximum speed: 5000 mm/min
  • Accuracy: 0.03 mm
  • Spindle: 2200W High frequency asynchronous
  • Spindle speed: 6000 - 24000 rpm/min
  • Spindle chuck: ER20 (1-13 mm)
  • Control software: RichAuto
  • Control electronics: Profi6 RichAuto
  • Sensors: Yes
  • Auto tool zero probe: Yes
  • Construction: Welded metal
  • Drive: Stepper Motors Nema34
  • Rails X/Y/Z: Prismatic HGR20
  • Transmmission X/Y/Z: Ball Screws
  • Dimensions: 2050 x 3500 x 1700 mm
  • Set of tools: Yes 10pcs
  • Training: Yes
  • Support: Phone/Online
  • Warranty: Yes

Detailed information

Product detailed description

The CNC Machine is made in the EU - Directly from the manufacturer!

CNC milling machine suitable for processing large format materials. The machine is suitable for milling, engraving, marking, carving... various materials such as plastic, plexiglass, laminate, plywood, wood, MDF and many others. The whole machine is designed for demanding operation in production. Quality HGR20 prismatic linear guides on all axes supplemented with ball screws to achieve the highest precision. Thanks to the used Nema34 12Nm motors, the machine has sufficient power even for processing hard materials. The machine is equipped with a 2200W spindle with a maximum speed of 24000 rpm. All axes are provided with inductive end sensors, which also serve to focus the machine zero. The machine is controlled by the RichAuto software for easy operation that anyone can handle.

We are a machine manufacturer, we will be happy to adapt the machine to your requirements, or we can make a custom-made machine for you.

The CNC machine includes:

  • CNC Machine Kompas F3000
  • 2200W Spindle
  • Inductive sensors
  • Tool length sensor
  • 10 pcs of tools
  • Collet set ER20
  • Wrenches
  • RichAuto software
  • Basic training
  • Support
  • Warranty

The machine is suitable for processing:

  • Wood, Plywood, MDF
  • Plastic, Plexiglas, PVC
  • Composite, PCB, Laminate
  • Foam, Foil, Leather
  • Rubber, Cardboard
  • Gold, Silver, Bronze
  • Aluminium, Brass, Copper
  • Stone, Marble







All videos you can watch here: YouTube




In case of any questions, do not hesitate to contact us.



Miroslav Dudas

+421 915 451 978

info@cnc1.eu



Jan Dudas

+421 905 248 550

cnc1@cnc1.eu



Additional parameters

Category: CNC Routers
Weight: 550 kg
