Profi6 RichAuto A11 complet
Code: 1427Product detailed description
Product Feature
- New three-axis linkage motion mode to achieve comprehensive controlling
- Support XYZ axis driver and spindle error alarm function
- Large storage space, perfect U disk compatibility, fast reading speed, safe and reliable U disk-processing.
- Support intelligent file checking function.
- Parameter backup and restore function to prevent the loss of important parameters.
- High anti-jamming intensity passes many CE tests.
- Intelligent processing memory, supports power fail safeguard and breakpoint function.
- Definable I/O interfaces provide customers a wide range of development platforms.
Product Parameters
| Product Model | RichAuto----A11 |
| CPU | DSP |
| Internal Memory | 512Mb |
| Display Screen | 128*64 Monochrome LCD |
| Communication Port | USB |
| Controlled Axis Number | 3 axis |
| Control Signal | differential signal |
| Drive System | step motor/servo motor |
| Minimum Input Unit | 0.001mm |
| No Volt Protection | Support |
| Breakpoint Processing Function | Support |
| External Power Supply Voltage | 24V DC |
| Manual Mode | Continuous、point move、distance |
| Interpolation Method | line、arc、curve |
| Soft/Hard Limit | support |
| Maximum Pulse Frequency | 1M/S |
| Password Protection | support |
| Support Language | simple Chinese/traditional Chinese、English、other languages |
| Standard Configuration | (1) DSP Handle；(1) 50 core cable (1)USB cable； (1)8 I/O Wiring board |
Box size:
Length: 46cm
Width: 38cm
Depth: 12.5cm
